Name: Cordless Perfect Honeycomb Shades Light Filtering and Room Darkening - 9/16" Single Cell
SKU: 1043
Availability: InStock

Light Filtering

Brilliant White C7015K

Cotton Cloud C7016K

Gardenia C7017K

Soft Stone C7018K

French Silver C7135K

Iron Mountain C7138K

Dew C7142K

Silver Dusk C7143K

Space Gray C7208K

Natural Tan C7423K

Pale Oak C7424K

Whipped Mocha C7425K

Wheat C7427K

New Camel C7516K

Florida Keys C7617K

Bella Blue C7715K

Room Darkening

Brilliant White C4008T

Cotton Cloud C4009T

Gardenia C4010T

Soft Stone C4011T

French Silver C4123T

Iron Mountain C4126T

Silver Dusk C4130T

Dew C4131T

Space Gray C4205T

Natural Tan C4420T

Pale Oak C4421T

Whipped Mocha C4422T

Wheat C4427T

New Camel C4518T

Florida Keys C4609T

Bella Blue C4708T

Cordless honeycomb shades improve comfort with superior insulation and light control. Moreover, the cellular structure traps air for better energy efficiency. The cordless system ensures safe and smooth operation. Additionally, dual light options adapt to any room. Therefore, these shades deliver modern style with practical performance.

Features Cordless Honeycomb Shades:

· Advanced Insulation Design : Honeycomb cells trap air to regulate indoor temperature. Additionally, they reduce heat loss in winter. Therefore, energy efficiency improves throughout the year.

· Dual Light Control Options : Choose light filtering for soft daylight. Moreover, select room darkening for maximum privacy. Consequently, these shades suit bedrooms and living spaces.

· Cordless Safety System : Smooth lift mechanism removes exposed cords completely. Additionally, it improves safety for children and pets. Therefore, operation feels secure and effortless.

· UV Protection Performance : Blocks 88 to 97 percent of harmful UV rays. Furthermore, it protects furniture from fading. As a result, interiors stay bright yet protected.

· Custom Fit Flexibility : Designed for various window sizes and configurations. Additionally, multiple lift and control options are available. Consequently, installation becomes precise and seamless.

Product Colors:

Sample 1

Sample 2

Sample 3

Sample 4

Sample 5

Shipping Information:

* All fields below are required

Name

Address

City

State

ZIP

E-mail

Size Considerations

Lift System/Product	Width		Length		Max Area (sqft)
Lift System/Product	Min	Max	Min	Max	Max Area (sqft)
Cordless (3/8" SC, 9/16" SC)	11 1/2"	96"	10"	86"	60
Cordless (3/4" SC & DC, 1/2" DC, 1-1/4" SC)	11 1/2" ¹	120"	10"	120" ¹	100
Cordless TDBU	15"	96"	10"	86"	60
SmartFit™ (3/8" SC)	8 1/2"	50"	6"	86"	30
SmartFit™ (9/16" SC, 3/4" SC & DC, 1/2" DC, 1-1/4" SC)	8 1/2"	72"	6"	86"	43
Decoflex™ ²	10 1/2"	51 15/16"	8"	88"	31.7
Motorized Cordless	22"	120"	10"	144"	80
Motorized Cordless TD	31" ³	120"	10"	144"	50

When the length is greater than 86", the minimum width is 32 1/2"
All Decoflex measurements are maximum frame to frame
Minimum width is 35" for lengths greater than 72"

Standard Deductions

Product	Mounting	Shade Width(X)			Shade Height(Y)			PVC light guard length
Product	Mounting	Order Width	Measurement	Tolerance	Order Height	Measurement	Tolerance	PVC light guard length
Cordless	OB	X=Order Width	Measure shade from left to right	±1/8"	Y=Order Height	Measure from the top of the headrail to the bottom of bottom rail (when the shade is at full extension)	+1/2" ~ +3"	N/A
Cordless TDBU	OB	X=Order Width		±1/8"	Y=Order Height		+1/2" ~ +3"	N/A
Motorized Cordless	IB	X=Order Width-3/8"		±1/8"	Y=Order Height		+3/8" ~ +1 1/4"	Order Height - 1/8"
Motorized Cordless TD	IB	X=Order Width-3/8"		±1/8"	Y=Order Height		+3/8" ~ +1 1/4"	Order Height - 1/8"
SmartFit	IB	X=Order Width - 1/4" (without PVC light guard)		±1/8"	Y=Order Height		Cords can be adjusted a bit to better fit your window in height	Order Height

Other Products:

Decoflex (Max Frame to Frame Size):
- Width: measure from left L frame to right L frame
- Height: measure from top L frame to bottom L frame

Mounting Depths

Lift Systems	3/8" Single		9/16" Single		1/2" Double		3/4" Single		3/4" Double		1 1/4" Single
Lift Systems	Inside Mount	Semi-IM	Inside Mount	Semi-IM	Inside Mount	Semi-IM	Inside Mount	Semi-IM	Inside Mount	Semi-IM	Inside Mount	Semi-IM
Cordless	2 1/4"	1 1/2"	1 13/16"	1"	2 1/4"	1 1/2"	2 1/4"	1 1/2"	2 11/16"	1 7/16"	2 11/16"	1 7/16"
Cordless TDBU	2 1/4"	1 5/16"	2 1/4"	1 5/16"	2 1/4"	1 5/16"	2 1/4"	1 5/16"	2 11/16"	1 7/16"	2 11/16"	1 7/16"
SmartFit	1 3/16"	N/A	1 9/16"	N/A	1 7/8"	N/A	1 7/8"	N/A	2 5/8"	N/A	2 5/8"	N/A
Motorized Cordless (Battery wand)	3 9/16"	2 5/8"	3 9/16"	2 5/8"	3 9/16"	2 5/8"	3 9/16"	2 5/8"	3 9/16"	2 3/8"	3 9/16"	2 3/8"
Motorized Cordless	2 1/4"	1 5/16"	2 1/4"	1 5/16"	2 1/4"	1 5/16"	2 1/4"	1 5/16"	2 11/16"	1 7/16"	2 11/16"	1 7/16"
Motorized TD (Battery wand)	3 9/16"	2 5/8"	3 9/16"	2 5/8"	3 9/16"	2 5/8"	3 9/16"	2 5/8"	3 9/16"	2 3/8"	3 9/16"	2 3/8"
Motorized TD	2 1/4"	1 5/16"	2 1/4"	1 5/16"	2 1/4"	1 5/16"	2 1/4"	1 5/16"	2 11/16"	1 7/16"	2 11/16"	1 7/16"

For more detailed information about the product, its specifications, options and technical manuals.

Perfect Honeycomb Shades – Program Reference Guide

Cordless, Cordless TDBU – Installation Instructions

SmartFit^™ – Installation Instructions

Decoflex^™ – Installation Instructions

Motorization – Installation Instructions

Motorized shades basic programming

Battery Wand Troubleshooting

PVC Light Guard – Installation Instructions

Light Control Options

Light Filtering: 88% to 97% UV blockage
Room Darkening: 100% UV blockage

Lift Systems & Applications

Cordless
Cordless Top Down/Bottom Up
SmartFit™
Decoflex™
Motorized

Light Guard

PVC
Inside mount only
Light guard is not available in Decoflex

Cut-outs

Lengths are measured up from the bottom of bottom rail
Cut-outs are made when the shade is fully extended
Provide detailed information under "Notes" when ordering
Cut-outs are not available for SmartFit™, Cordless TDBU
Cut-outs will be made on the bottom rail and the bottom section of the fabric
Cut-out location options
- Bottom Corner (Left)
- Bottom Corner (Right)
- Bottom Corners (Both)

Hold Downs

Choose from Traditional or Magnetic hold-down brackets (one for the left and the right side of shade) to secure the shade in place when closed

Traditional Hold-Down
Magnetic Hold-Down
- Available for OM only
- Not recommended for metal door applications
- The magnet will be attached at the factory before shipping
- The magnet catch will need to be installed at the job site

Shim (Spacer Block)

Dimensions: 41mm (1.614") x 10mm (0.394")
Up to 3 Spacer Blocks can be stacked per bracket

Although the color scans on this web site were scanned with the highest quality scanner, not all computer monitors are the same and do not necessarily display colors the same way. It is recommended that you have your video resolution adjusted to 800 x 600 or greater and your color depth set to 16 bit (high color) or 32 bit (true color). Most modern computers are capable of displaying 16.7 million colors at one time in 32 bit mode.

If an exact color match is required request a sample. If samples are available for the product you are interested in please request a swatch.

Wood Blinds

It is considered normal for wood to take stain differently. A difference in color across the grain is normal. If you are planning to order blinds for your whole house we recommend ordering them all at one time. Your order will be filled using slats from the same batch. If you order the same color at a later date it is very likely that it will come from a different die lot and will not match exactly. We do not guarantee color matching a previous order.

It is also normal for painted (white) slats to vary slightly in shade from one batch to the next. We cannot guarantee an exact match if you order blinds at separate times.

If you must order blinds at different times we recommend doing so by room. Order all the blinds that are going in the same room at the same time.

Faux Blinds

Faux wood blinds will also vary slightly in color from one die lot to the next, but the main color will be consistent.
