Specifications:
Size Considerations
· Cordless (3/8" SC, 9/16" SC) : Min width 11-1/2", max width 96", min height 10", max height 86", max area 60 sq ft
· Cordless (3/4" SC and DC, 1/2" DC, 1-1/4" SC) : Min width 11-1/2" (32-1/2" for lengths over 86"), max width 120", min height 10", max height 120", max area 100 sq ft
· Cordless TDBU : Min width 15", max width 96", min height 10", max height 86", max area 60 sq ft
· SmartFit (3/8" SC) : Min width 8-1/2", max width 50", min height 6", max height 86", max area 30 sq ft
· SmartFit (9/16" SC, 3/4" SC and DC, 1/2" DC, 1-1/4" SC) : Min width 8-1/2", max width 72", min height 6", max height 86", max area 43 sq ft
· Decoflex : Min width 10-1/2", max width 51-15/16", min height 8", max height 88", max area 31.7 sq ft (all max frame to frame)
· Motorized Cordless : Min width 22", max width 120", min height 10", max height 144", max area 80 sq ft
· Motorized Cordless TD : Min width 31" (35" for lengths over 72"), max width 120", min height 10", max height 144", max area 50 sq ft
Standard Deductions
· Cordless and Cordless TDBU — Outside Mount : Shade width equals order width. Shade height equals order height. Tolerance plus or minus 1/8 inch.
· Motorized Cordless and Motorized TD — Inside Mount : Shade width equals order width minus 3/8 inch. Shade height equals order height. PVC light guard length equals order height minus 1/8 inch.
· SmartFit — Inside Mount : Shade width equals order width minus 1/4 inch (without PVC light guard). Shade height equals order height. Cords adjustable for height fit.
· Decoflex : All measurements are maximum frame to frame. Width from left L frame to right L frame. Height from top L frame to bottom L frame.
Mounting Depths
· Cordless — 3/8" single cell : Inside mount 2-1/4", semi-IM 1-1/2"
· Cordless — 9/16" single cell : Inside mount 1-13/16", semi-IM 1"
· Cordless — 3/4" double cell : Inside mount 2-11/16", semi-IM 1-7/16"
· Cordless TDBU — all cells : Inside mount 2-1/4" to 2-11/16", semi-IM 1-5/16" to 1-7/16"
· SmartFit — 3/8" single cell : Inside mount 1-3/16", semi-IM not available
· SmartFit — 9/16" single cell : Inside mount 1-9/16", semi-IM not available
· SmartFit — 3/4" double cell : Inside mount 2-5/8", semi-IM not available
· Motorized Cordless Battery Wand — all cells : Inside mount 3-9/16", semi-IM 2-5/8" or 2-3/8"
· Motorized Cordless — all cells : Inside mount 2-1/4" to 2-11/16", semi-IM 1-5/16" to 1-7/16"
· Motorized TD Battery Wand — all cells : Inside mount 3-9/16", semi-IM 2-5/8" or 2-3/8"
· Motorized TD — all cells : Inside mount 2-1/4" to 2-11/16", semi-IM 1-5/16" to 1-7/16"
Controls and Options
· Cell sizes : 3/8" single, 3/4" single, 1-1/4" single
· Lift systems : Cordless, Cordless TDBU, SmartFit, Decoflex, Motorized Bottom Up, Motorized Top Down
· Motor options : Battery Wand or AC Adaptor
· Remote control : Yes or No
· Mount position : Inside or Outside
· PVC light guard : Yes or No — inside mount only, not available in Decoflex
· Cut-out : Yes or No — bottom left, right, or both corners (not available for SmartFit or Cordless TDBU)
· Hold downs : Traditional or Magnetic (magnetic outside mount only)
· Spacer block : Yes or No — 41mm x 10mm, up to 3 per bracket
· Width increments : Even, 1/8, 1/4, 3/8, 1/2, 5/8, 3/4, 7/8 inch
· Length increments : Even, 1/8, 1/4, 3/8, 1/2, 5/8, 3/4, 7/8 inch
Color Options
· Seapearl C5001
· Cloudy Chiffon C5002
· Cloud White C5004
· Nightfall C5201
· Jersey Cream C5501
