Specifications:
Size Definition — Continuous Cord Loop
· Minimum width : 12 inches
· Maximum width : 98 inches
· Minimum height : 12 inches
· Maximum height : 98 inches
· Ratio limit : Height cannot exceed four times the width (1:4 ratio for all fabrics)
Size Definition — Motorized
· Minimum width : 14 inches
· Maximum width : 110 inches
· Minimum height : 12 inches
· Maximum height : 120 inches
· Ratio limit : Height cannot exceed four times the width (1:4 ratio for all fabrics)
Shade Width Measurement
· With valance : Measured from left edge of bracket to right edge of bracket
· With fascia : Measured from left edge of end cap to right edge of end cap
Shade Height Measurement
· Height : Measured from top of raceway to bottom of hem bar when shade is completely lowered
Inside Mount Deductions
· Shade width : Order width minus 1/8 inch
· Shade height : Order height — no deduction
Outside Mount Deductions
· Deduction : None — shade width and height equal order dimensions exactly
Controls and Options
· Lift system : Continuous Cord Loop or Motorized (AutoWand)
· Motor : Yes or No
· Remote control : Yes or No
· Lift position : Left or Right (default Right)
· Mount position : Inside or Outside
· Top treatment : Curved fascia with fabric insert (standard), 4-1/2 inch modern wood valance, 4-1/2 inch fabric valance
· Wood valance finishes : Pure White, Silk White, Pearl, Crisp Linen, Stone Gray, Clay, Limed White, Dark Teak, Weathered Teak, Wenge, Black Walnut, Matte Black
· Light guard : Wood or Aluminum
· Hold downs : Traditional or Magnetic
· Spacer block : Yes or No
· Width increments : Even, 1/8, 1/4, 3/8, 1/2, 5/8, 3/4, 7/8 inch
· Length increments : Even, 1/8, 1/4, 3/8, 1/2, 5/8, 3/4, 7/8 inch
